Description
Technical Specifications
| Conductor Size (mm²) | Overall Diameter (mm) | Cable Weight (kg/km) | Max. DC Resistance at 20°C (Ohm/km) | Current Carrying Capacity in Ground (A) | Current Carrying Capacity in Air (A) |
| 3×16/10 | 24.0 | 1400 | 1.15 | 111 | 98 |
| 3×25/16 | 27.0 | 1900 | 0.727 | 143 | 126 |
| 3×35/16 | 29.5 | 2300 | 0.524 | 173 | 156 |
| 3×50/25 | 33.0 | 3000 | 0.387 | 205 | 190 |
| 3×70/35 | 38.0 | 4200 | 0.268 | 252 | 245 |
| 3×95/50 | 42.0 | 5300 | 0.193 | 303 | 297 |
| 3×120/70 | 48.0 | 7000 | 0.153 | 346 | 346 |
| 3×150/70 | 52.0 | 8000 | 0.124 | 390 | 398 |
| 3×185/95 | 57.0 | 10000 | 0.0991 | 441 | 455 |
| 3×240/120 | 62.0 | 12000 | 0.0754 | 511 | 535 |
| 3×300/150 | 64.0 | 15300 | 0.0601 | 580 | 630 |
| 3×400/185 | 80.0 | 21000 | 0.0470 | 663 | 740 |
