Description
Technical Specifications
| Conductor Size (mm²) | Overall Diameter (mm) | Cable Weight (kg/km) | Max. DC Resistance at 20°C (Ohm/km) | Current Carrying Capacity in Ground (A) | Current Carrying Capacity in Air (A) |
| 4×10 | 21.0 | 1000 | 1.83 | 86 | 73 |
| 4×16 | 23.0 | 1300 | 1.15 | 111 | 98 |
| 4×25 | 26.5 | 1800 | 0.727 | 143 | 126 |
| 4×35 | 30.0 | 2300 | 0.524 | 173 | 156 |
| 4×50 | 33.0 | 2900 | 0.387 | 205 | 190 |
| 4×70 | 37.5 | 4000 | 0.268 | 252 | 245 |
| 4×95 | 41.5 | 5100 | 0.193 | 303 | 297 |
| 4×120 | 46.5 | 6500 | 0.153 | 346 | 346 |
| 4×150 | 52.0 | 7700 | 0.124 | 390 | 398 |
| 4×185 | 57.0 | 9700 | 0.0991 | 441 | 455 |
| 4×240 | 63.0 | 12000 | 0.0754 | 511 | 535 |
| 4×300 | 70.0 | 15300 | 0.0601 | 580 | 630 |
| 4×400 | 81.0 | 19750 | 0.0470 | 663 | 740 |
| 5×10 | 22.5 | 1100 | 1.83 | 86 | 73 |
| 5×16 | 25.0 | 1450 | 1.15 | 111 | 98 |
| 5×25 | 29.0 | 2020 | 0.727 | 143 | 126 |
| 5×35 | 32.0 | 2600 | 0.524 | 173 | 156 |
| 5×50 | 36.0 | 3300 | 0.387 | 205 | 190 |
| 5×70 | 41.5 | 4450 | 0.268 | 252 | 245 |
| 5×95 | 46.0 | 5700 | 0.193 | 303 | 297 |
| 5×120 | 51.0 | 7100 | 0.153 | 346 | 346 |
| 5×150 | 57.0 | 8600 | 0.124 | 390 | 398 |
| 5×185 | 63.0 | 10600 | 0.0991 | 441 | 455 |
| 5×240 | 70.0 | 13300 | 0.0754 | 511 | 535 |
