Description
Technical Specifications
| Conductor Size (mm²) | Approx. Outer Diameter (mm) | Cable Weight (kg/km) | Conductor Resistance at 20°C Max. (Ohm/km) | Current Carrying Capacity Underground (20°C) (A) | Current Carrying Capacity Free Air (30°C) (A) |
| 1×25 | 16.0 | 500 | 0.727 | 179 | 180 |
| 1×35 | 18.0 | 650 | 0.524 | 213 | 225 |
| 1×50 | 20.0 | 800 | 0.387 | 251 | 273 |
| 1×70 | 22.0 | 1000 | 0.268 | 307 | 350 |
| 1×95 | 24.0 | 1300 | 0.193 | 366 | 428 |
| 1×120 | 27.0 | 1600 | 0.153 | 416 | 495 |
| 1×150 | 30.0 | 1950 | 0.124 | 465 | 575 |
| 1×185 | 32.0 | 2350 | 0.0991 | 526 | 660 |
| 1×240 | 34.0 | 2900 | 0.0754 | 610 | 780 |
| 1×300 | 37.0 | 3850 | 0.0601 | 689 | 864 |
| 1×400 | 41.0 | 4900 | 0.0470 | 788 | 1018 |
