Description
Technical Specifications
| Model / Designator | Bolt Hole Dia. φ±0.5 (mm) | Barrel Outer Dia. D±0.5 (mm) | Barrel Inner Dia. d±0.5 (mm) | Overall Length L±2 (mm) |
| SC-A-6 | φ6.5, φ8.5 | 6 | 4.8 | 24.5 |
| SC-A-10 | φ6.5, φ8.5 | 8 | 5.8 | 39 |
| SC-A-16 | φ6.5, φ8.5, φ10.5 | 9 | 6.5 | 42 |
| SC-A-25 | φ6.5, φ8.5, φ10.5 | 10 | 7.6 | 47 |
| SC-A-35 | φ6.5, φ8.5, φ10.5 | 11 | 8.5 | 52 |
| SC-A-35 | φ12.5 | 11 | 8.8 | 52 |
| SC-A-50 | φ8.5, φ10.5, φ12.5 | 13 | 10 | 54 |
| SC-A-70 | φ8.5, φ10.5, φ12.5 | 16 | 12 | 62 |
| SC-A-95 | φ8.5, φ10.5, φ12.5, φ14.5 | 18 | 14 | 64 |
| SC-A-120 | φ10.5, φ12.5 | 19 | 15 | 72 |
| SC-A-150 | φ10.5, φ12.5, φ14.5, φ16.5 | 21 | 16.8 | 68 |
| SC-A-185 | φ12.5, φ14.5, φ16.5 | 24 | 18.8 | 86 |
| SC-A-240 | φ12.5, φ14.5, φ16.5 | 26 | 21 | 91 |
| SC-A-300 | φ16.5 | 30 | 24 | 99 |
| SC-A-400 | φ16.5 | 31.9 | 25.7 | 110 |
| SC-A-500 | φ20.5 | 38 | 30 | 116 |
| SC-A-630 | φ20.5 | 45 | 36.3 | 135 |
