Description
Technical Specifications
| Conductor Size (mm²) | Overall Diameter (mm) | Cable Weight (kg/km) | Max. DC Resistance at 20°C (Ohm/km) | Current Carrying Capacity in Ground (A) | Current Carrying Capacity in Air (A) |
| 3×16/10 | 24.5 | 1325 | 1.15 | 102 | 79 |
| 3×25/16 | 28.0 | 1850 | 0.727 | 133 | 100 |
| 3×35/16 | 30.0 | 2250 | 0.524 | 159 | 125 |
| 3×50/25 | 34.0 | 2900 | 0.387 | 188 | 153 |
| 3×70/35 | 38.0 | 3800 | 0.268 | 232 | 195 |
| 3×95/50 | 43.0 | 4950 | 0.193 | 280 | 238 |
| 3×120/70 | 47.0 | 6150 | 0.153 | 318 | 275 |
| 3×150/70 | 51.0 | 7150 | 0.124 | 359 | 320 |
| 3×185/95 | 56.0 | 8950 | 0.0991 | 406 | 364 |
| 3×240/120 | 62.0 | 11000 | 0.0754 | 473 | 430 |
| 3×300/150 | 67.0 | 14000 | 0.0601 | 535 | 510 |
| 3×400/185 | 78.0 | 18000 | 0.0470 | 613 | 595 |
